Product Description
The MPU6500 is a high-performance 6-axis motion tracking module that combines a 3-axis gyroscope and a 3-axis accelerometer on a single chip. It features an integrated Digital Motion Processor (DMP) that handles complex motion calculations, offloading the processing burden from the main microcontroller. Designed for low-power operation, it is ideal for battery-dependent devices like drones, wearables, and autonomous robots. The module supports both I2C and SPI communication protocols, offering high-speed data updates for precise real-time orientation and gesture detection.
Product Specifications
- Chip MPU-6500
- Operating Voltage 3V to 5V DC (via an internal regulator; the chip itself runs on 1.71V–3.6V)
- Dimensions (L x W x H) 25 mm x 15 mm x 3 mm (some variants are 26 x 15 mm or 22 x 17 mm)
- Weight Approximately 1 g to 3 g (module only)
- Interface Standard I2C and SPI communication protocols
- Gyroscope Range Programmable ±250, ±500, ±1000, ±2000°/s
- Accelerometer Range Programmable ±2g, ±4g, ±8g, ±16g
- Resolution 16-bit ADC for high precision"
